Hanna Instruments HI1285-6 pH electrode replacement for HI9813-6

Hanna Instruments HI1285-6 pH electrode replacement for HI9813-6

Hanna Instruments

  • $ 10475


Hanna Instruments HI1285-6 Preamplified pH and EC Probe with DIN Connection

HI1285-6 pH electrode replacement for HI9813-6

Product Features

  • pH and electro-conductivity (EC) probe for greenhouses, hydroponics, environmental monitoring, water treatment, boilers, and cooling towers
  • Single cloth junction to reduce contamination and Automatic Temperature Compensation (ATC) provided by internal thermometer sensor for accurate readings in fluctuating temperatures
  • Polypropylene plastic body with spherical tip for general purpose and field applications
  • Internal amplifier for a strong low impedance signal from the electrode to HI 9813 series portable meters and calibration check status capability
  • Comes with seven-pole 2m (6.6') cable and has Deutsches Institut für Normung (DIN) connector for tight cable connections


Product Description

The Hanna Instruments HI 1285-6 is a pH and electro-conductivity (EC) electrode for HI 9813 series portable meters and has a single cloth junction, Automatic Temperature Compensation (ATC), polypropylene plastic body, spherical tip, internal amplifier, Deutsches Institut für Normung (DIN) connector, and a seven-pole 2m (6.6') cable. A pH electrode is commonly attached to a pH meter to measure the pH of a substance such as water, food, beer, or wine in lab, industrial, and food applications. An internal thermometer sensor in this electrode provides ATC for accurate readings in fluctuating temperatures. The single cloth junction reduces contamination. The polypropylene plastic body with 8mm spherical tip is for general purpose and field applications. An internal amplifier provides a strong low impedance signal from the electrode to the meter. The electrode has calibration check capability when using the HI 9813 series portable meters. A DIN connector provides a tight cable connection and the electrode comes with seven-pole 2m (6.6') cable.

Specifications

pH range 0 to 13
Junction Cloth
Electrolyte Gel
Reference Single Ag/AgCl
Body material Polypropylene
Operating temperature 20 to 40 degrees C (68 to 104 degrees F)
Maximum pressure 0.1 bar
Connector DIN
Cable 2m (6.6') seven-pole

An electrode, also called a sensor or probe, is an instrument used with a meter to test and measure parameters of a substance. All electrodes are probes or sensors, but not all probes are electrodes or sensors. Probes, such as temperature probes, are used to penetrate a material for measurement. Common electrode types are pH, total dissolved solid (TDS), and ion selective electrode (ISE). Electrodes can be half-cell or full-cell (also called combination) types. They can be refillable or non-refillable. Housing material is typically glass or epoxy, and sensors are commonly made with stainless steel or a glass bulb. pH electrodes, which measure the pH of a substance, often have a glass bulb. The bulb senses hydrogen ions, and generates a millivoltage that is picked up by the filling solution and transferred to a wire that connects to the pH meter. Ion selective electrodes (ISEs) respond selectively to ions in the presence of other ions. Electrodes are commonly used by researchers, manufacturers, and hobbyists in a wide variety of industries, such as aquaculture, agriculture, chemistry, food and beverage, wine-making and water-testing, and for scientific applications. An electrode can be used with a datalogger to assist in temperature measurement.

Hanna Instruments manufactures analytical instrumentation and supplies, including pH meters, electrodes, chemical reagents, and buffer solutions. The company, founded in 1978 and headquartered in Woonsocket, RI, meets International Organization for Standardization (ISO) standard 9001.
